PRO12-48M ™ for 48 Volt EZGO, Yamaha, Club Car Battery Meter

• The battery meter has 10 LEDS that will light to show the battery condition. When fully charged, only the 10th LED will light shown a green LED.
• As the battery discharges, successively lower LEDs will light; the 9th, 8th, 7th and so on lighting only 1 LED.
• At approximately 30% battery life, the #3 LED will light and the color is Yellow as a caution indicator.
• At approximately 20% battery life remaining, the #2 LED will light as a Flashing Yellow.
• When the battery discharges to approximately ~10% remaining life, the #1 LED will start FLASHING RED with the #2 LED FLASHING Yellow alternately.

It is recommended to have the battery or batteries recharged when the #3 LED lights Yellow as a safety margin to prevent dead batteries.

CAUTION: This is not a full proof device and no warranty is made that your battery/batteries is/are in good condition.

Reading

10 LEDs, #10 being fully charged and #1 being fully discharged

Voltage Indicator Range for Golf Carts, Fork Lift Trucks and other battery powered equipment.

48 Volt Range - Cruve #1 49.31 volts Full; 41.52 volts Empty

48 Volt Range - Cruve #2 50.88 volts Full; 46.23 volts Empty

Weight

2 Ounces

Voltage Supply

48 Volts DC

Temperature Range

-40 to 185 Fahrenheit; -40C to 85C

Power Consumption

20 ma max (0.020 Amps)

Dimensions

• OD   2.25"
• Depth Behind front meter flange to end of mating female connector - 1 7/16 inches
• Hole size - 2 "
